Series4GWIFI router with sim card slot-CO01495-Veeddydropshipping
- $123.67
-
- $123.67
- Unit price
- per
Couldn't load pickup availability
Description
xBundle: 150M WIFI/300M WIFI
2.4G Wi-Fi Transmission Rate : 300 Mbps
Wi-Fi Supported Frequency : 2.4G
Supports WPS : Yes
LAN Ports : 2
Function : Firewall
Application : ENTERPRISE
Package : Yes
Standards And Protocols : Wi-Fi 802.11g,Wi-Fi 802.11b,Wi-Fi 802.11n
Model Number : R220 Series
housing : Metal
Port Forwarding : Supported
Remote Web Management : Supported
Antenna : external removable
Max. LAN Data Rate : 300Mbs
|
R320 series Router is industrial grade router, combined wired/wireless/3G/4G network connection device designed specifically for M2M application. |
|
|
Data rate up to 150Mbps |
|
Wireless security encryption easily at a push of "WPS" button, to establish very safe WPA secure connection | ||
Built in 3G module and SIM card slot | ||
Physical Specification |
Interface |
LAN:10/100M Auto MDI/MDIX RJ45 port* 2 |
LED |
|
POWER, WLAN, LAN1,LAN2, 3G, WPS |
|
Black |
|
Network Media |
10BASE-T |
UTP category 3, 4, 5 cable (maximum 100m) |
EIA/TIA-568 100Ω STP (maximum 100m) | ||
100BASE-TX |
UTP category 5, 5e cable (maximum 100m) |
|
EIA/TIA-568 100Ω STP (maximum 100m) | ||
Antenna |
Antenna Gain |
5dBi * 1 |
Orientation |
Omni-directional |
|
Fixed or Detachable |
SMA interface Detachable Antenna |
|
|
Original PSU Specification |
Switching PSU |
Power Input |
100-240V/50-60Hz |
|
Power Output |
12VDC/2.0A |
|
Power Consumption |
7.3W (depends on used cellular module) |
|
|
Frequency Band |
2.4~2.4835GHz |
Extend Frequency |
DSSS |
|
Modulation Type |
DBPSK, DQPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM) |
|
Data Transmission Rates |
11n: Up to 300Mbps (Dynamic) |
|
Transmission Distance |
Indoor up to 100m, outdoor up to 300m |
|
|
1~11 (US, Canada) |
|
|
18dBm (max) |
|
|
130M: -68dBm@10% PER |
|
|
WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES) |
|
WiFi |
AP Router, AP+Bridge |
|
|
Default Manage Mode |
Web management |
DHCP |
DHCP server enabled |
|
Remote Management |
Disabled |
|
Wireless Operation Mode |
AP Mode |
|
Wireless Radio |
Enabled |
|
SSID |
Enable SSID Broadcast |
|
channel |
Auto |
|
Router Settings |
Internet Access Type: 3G only |
|
Security Settings |
Firewall Disabled |
|
Wireless Security Disabled | ||
|
|
Supports 802.11g, 802.11b, 802.3, 802.3u, Compatible with 802.11n |
Fully compatible with 802.11b/g products | ||
Supports TCP/IP, PPPoE, DHCP, ICMP, NAT | ||
|
Built-in DHCP server supporting static IP address distributing |
|
Built-in NAT server supporting Virtual Server, Special Application, and DMZ host | ||
Supports UPnP, Dynamic DNS, Static Routing, VPN pass-through | ||
Supports IP QoS | ||
Built-in firewall with IP address filtering, Domain Name filtering, and MAC address filtering | ||
Supports Flow Statistics | ||
Supports ICMP-FLOOD, UDP-FLOOD, TCP-SYN-FLOOD filter, DoS protection | ||
IP & MAC Binding | ||
|
Shares data and Internet access for users, supporting 3G, PPPoE, Dynamic IP, Static IP Internet access |
|
|
Supports Wireless Roaming |
|
Provide Wireless Statistics | ||
|
Provides 64/128/152-bit WEP encryption security |
|
Provides WPA/WPA2 and WPA-PSK/WPA2-PSK authentication and TKIP/AES encryption security | ||
Provides wireless LAN ACL (Access Control List) filtering | ||
System |
Easy firmware upgrade |
|
Remote Management | ||
|
CE, FCC, Compliant with RoHS |
|
|
IEEE Standards |
802.11g, 802.11b, 802.11i, 802.1X, 802.3, 802.3u, 802.3X, Compatiable with 802.11n |
Others Protocols and Standards |
CSMA/CA, CSMA/CD, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP |
|
|
|
-25°C to +65°C |
Storage Temperature |
-40°C |
|
Operating Humidity |
||
Storage Humidity |
||
|
Packing style of color box |
Sales package |
Package Contents |
4G Wireless Router |
|
Resource CD | ||
Power Supply Unit | ||
Quick Installation Guide | ||
4G Cellular Specifcation:
Cellular Module |
Industrial cellular module |
Standard and Band |
LTE FDD: B1/B3/B5/B7/B8/B20 (2100/1800/850/2600/900/800MHz) FDD:B1/B2//B3/B4/B5/B7/B8/B28(Optional) LTE TDD: B38/B40 HSPA+/HSUPA/HSDPA/WCDMA/UMTS 2100/1900/900/850MHz EDGE/GPRS/GSM 1900/1800/900/850MHz |
Bandwidth |
LTE(DL:150Mbps,UL:50Mbps) HSPA+: 21Mbps(Download speed) 5.76Mbps(Upload speed) HSUPA:5.76Mbps(Upload speed) HSDPA:7.2Mbps(Download speed) UMTS:384Kbps (DL/UL) |
